Techcon TSR2401 Benchtop Fluid and Adhesive Dispensing Robot
When to Use the Techcon TSR2401 Benchtop Dispensing Robot
The Techcon TSR2401 benchtop dispensing robot offers a simple interface, is easily programable and is the largest of the Teechcon TSR2000 Series units. This desktop robot can dispense a wide range of fluid and adhesive materials on a 400mm X 400mm work area.
The Techcon TSR2401 is used in a wide range of potting, bonding, sealing and gasketing applications.
All of the Techcon TSR2000 Series Benchtop Robots
- Techcon TSR2201: 200mm X 200mm Working Area
- Techcon TSR2301: 300mm X 300mm Working Area
- Techcon TSR2401: 400mm X 400mm Working Area
Details
The Techcon TSR2201 dispensing robot was designed for dispensing single component fluid and adhesive materials. It offers total control over the dispensing location and can extrude in lines, beads, dots and arcs.
Features of the Techcon TSR 2201 Benchtop Robot
- Simple to program and operate
- Compatible with industry standard valves and syringes
- Industrial design and construction
Common Applications
- Solder Paste Dispensing
- Gasketing
- Filling
- Potting
- Encapsulating
- Bonding
- Coating
Specifications
|
Features |
TSR2201 |
TSR2301 |
TSR2401 |
|
| Power Supply | 100V ~ 240V AC | |||
| Power Consumption | 80W | |||
| Number of Controllable Axes | 3 axis | |||
| Moving Range | X axis | 200mm | 300mm | 400mm |
| Y axis | 200mm | 300mm | 400mm | |
| Z axis | 100mm | 100mm | 100mm | |
| Speed Range | X/Y axis | 0.1~600 mm/sec | ||
| Z axis | 0.1~200 mm/sec | |||
| Repeatability Accuracy | X/Y/Z axis | 0.02mm | ||
| Resolution | X/Y/Z axis | 0.01mm | ||
| Loading Weight | Tool | 5 Kg | 7 Kg | 7 Kg |
| Head | 2 Kg | 4 Kg | 4 Kg | |
| Storage for Processing Files | Max. 255 files. | |||
| Working Ambient | Temperature | 0~40℃ | ||
| Relative Humidity | 20%~90% (no condensation) | |||
| Dimension (W×D×H) | 303x377x521 mm | 418×513×521 mm | 518×613×521 mm |
Questions about this product? Our team of adhesive specialists can help. Submit your questions and we'll get you answers right away.
